Osburn Stratford Zero Clearance Fireplace

Osburn Stratford Zero Clearance Fireplace



Here's what you've been hoping to find, a decorative and efficient wood fireplace that meets EPA particle emissions standards. That's saying a lot, but the Osburn Stratford has much more to offer, including a 2.5 cubic foot firebox that's easy to reach through double-cast iron doors. The Osburn Stratford will impress you with its distinctive style and exceptional heating capacity. Several options are available, including a forced air system for heating adjacent rooms. See the technical specifications of the Osburn Stratford - there's a world of possibilities waiting for you!

  • Description
  • Specifications
  • Photos (6)
  • Pricing
  • Add Review
Osburn Stratford

Features:

  • 75,000 BTU/hr.
  • Heating capacity: 750 to 2,100 sq.ft.
  • 2.5 cubic foot firebox
  • Log length up to 21"
  • Adjustable handle
  • Self-cleaning glass system
  • Heat-activated twin 150 CFM blower included
  • Approved on DuraVent - DuraTech Pipe
    Tested by OMNI as per applicable standards (CSA/UL/ULC and/or others)
  • Washington State approved with emissions of less than 4.4 g/hr.

Options:

  • Black or brushed nickel plated door overlay
  • Black or brushed nickel plated louver kit
  • Fireguard
  • 3" Adapter for fresh air kit
  • Hot air gravity kit
  • Forced air kit



Specifications Osburn Stratford
Type of fuel Wood
Recommended surface area to heat 750 to 2,100 sq.ft.
Blower 2 x 75 CFM
Color Metallic black
Exterior dimensions 37 7/8"W x 29 5/8"D x 47 1/8"H
Recommended chimney diameter 6" or (for 7" see the owner's manual)
Centre line of flue outlet to the back 10 1/8"
Centre line of flue outlet to the side 18"
Minimum chimney height 15'
Viewing Area 12-1/4” H x 11”W total viewing area 22”W x 12-1/4”H
Firebox dimensions 20 3/4"W x 12 1/2''H x 17 7/8"D
Log positioning East / West or North / South
Maximum log length 21"
Door opening dimensions 25 3/4"W x 10 7/8"H
Type of door Ceramic glass with cast iron frame and logo
Glass surface 11 1/8'' X 12 3/8''
Weight 424 lb (192 kg)
Warranty Limited lifetime
Test standard - safety ULC S-610/UL 127/NFPA 211/CSA B365, as applicable in Canada and in the USA.
Test standard - emissions EPA/CSA B415.1
BTU's 75,000 MAX
Approved chimney manufacturers Brand Type
Selkirk Ultra-Temp (UT) 1" Solid Pack
Selkirk Super Pro (SPR) 1" Solid Pack
Selkirk Super Vent (JSC) 1" Solid Pack
Selkirk Hart & Cooley (TLC) 1" Solid Pack
Selkirk Sure-Temp (ST) 1" Solid Pack
Selkirk CF Sentinel (CF) 2" Solid Pack
Selkirk Super Pro 2100 (ALT) 2" Solid Pack
Selkirk Super Vent 2100 (JM) 2" Solid Pack
Selkirk UltimateOne 1" Solid Pack
Security Chimney ASHT+ 1" Solid Pack
Security Chimney S-2100 + 2" Solid Pack
Dura Vent Dura Plus HTC 2" Solid Pack
Dura Vent Dura Plus AC Triple Wall
ICC Excel 2100 1" Solid Pack
Metal Fab Temp Guard 1" Solid Pack
American Metal HSS AC Triple Wall
American Metal HS AC Triple Wall
Olympia Chimney Ventis 1" Solid Pack
FMI (U.S.A. only) AC AC Triple Wall
Minimum clearances to combustibles * Inches (1 inch = 25.4 mm)
Sidewall 17"
Side facing 0"
Mantle (from floor) 50"
Back wall 0"
Floor 0"
Sides 0"
Non-combustible surface (side) 0"
Non-combustible surface (top) 0"

* The information given on the certification label affixed to the appliance always overrides the information published in any other media (owner's manual, catalogues, flyers, magazines and/or web sites).


Osburn Stratford Zero Clearance Fireplace

Osburn Stratford Zero Clearance Fireplace

Osburn Stratford Zero Clearance Fireplace

Osburn Stratford Zero Clearance Fireplace

Osburn Stratford Zero Clearance Fireplace

Osburn Stratford Zero Clearance Fireplace
Osburn Stratford Retail
Stove with Original Finish * Must Choose Overlay and Faceplate - See Options Below* $2,299
REQUIRED - Must Choose Overlay
BLACK Cast Iron Door Overlay $220
Brushed NICKEL Cast Iron Door Overlay $530
REQUIRED - Must Choose Faceplate
Traditional Style Faceplate $480
Prairie-Style Faceplate $500
Traditional Faceplate with Brushed Nickel Accents $590
OPTIONS
Fire Screen $110
Forced Air Distribution Kit 300 CFM $599
Gravity Kit - Traditional Style $250
3" Insulated Flex duct (10 ft) $50
25' x 6"' Insulated Flex Pipe for Forced Air Kit $145

Shipping is included (within the continental U.S.) in the above prices when the stove or fireplace is ordered. Single shipments of accessories may have a shipping charge.

Please call or Email for a complete quote with our discounted price on chimney pipe.



All Retail Prices Include: Residential, curbside delivery via freight truck with a lift gate is included for shipping in the Continental U.S.A. (some exceptions may apply). Please inquire with our sales staff if you have specific shipping needs such as international, freight terminal and/or business deliveries or if you need a smaller truck size. Click here to see Obadiah's Shipping Terms.

Obadiah's offer's a 20% discount and free shipping on most complete chimney systems. Email our chimney specialists for an exact quote.
