Osburn Matrix Wood Stove

Osburn Matrix Wood Stove

The Matrix wood stove uses the same engine as the proven Osburn 2000. However, its clean and modern look is sure to bring a European touch to your room. The top of the stove is made of cast iron with two rich pieces of soapstone, which remind us of the renowned Finnish fireplaces. Optional soapstone side shields are also available. Logs can be conveniently placed underneath the large firebox, making the Matrix a practical and elegant heating machine.

  • Description
  • Specifications
  • Pricing
  • Videos (2)
  • Add Review

The Matrix wood stove uses the same engine as the proven Osburn 2000. However, its clean and modern look is sure to bring a European touch to your room. The top of the stove is made of cast iron with two rich pieces of soapstone, which remind us of the renowned Finnish fireplaces. Optional soapstone side shields are also available. Logs can be conveniently placed underneath the large firebox, making the Matrix a practical and elegant heating machine.

Features:

Model # : OB02020

  • High-efficiency appliance EPA approved
  • Recommended Heating Area (sq. ft.) : 750 - 2,100
  • Blower Included
  • Color : Metallic black
  • Model : Pedestal
  • Easy-to-access ash drawer
  • Glass air-wash system
  • Steel thickness (top) : 5/16"
  • Optimum efficiency : 77.2 %
  • Emissions (grams/hour) : 3.89 g/h
  • Baffle : High heat-resistant C-cast
  • Firebox lined with refractory bricks for better heat distribution
  • Stainless-steel secondary-air system improving gas combustion
  • Recommended chimney diameter : 6"
  • May qualify for some government incentives.
  • Tested or/and listed as per applicable standards by : Intertek

Options

  • Firescreen
  • Adapter for fresh air kit
  • Fresh air kit with 5" dia x 4' long Insulated pipe
Technical Specifications Osburn Matrix Wood Stove
Firebox (Width) 21"
Firebox (Height) 12"
Firebox (Depth) 16-1/2"
Maximum Log Length 20"
Door Opening (Width) 17-1/2"
Door Opening (Height) 8-3/4"
Type of Door Single, glass with cast iron frame
Glass Surface Area 19-5/8" x 11-7/8"
Maximum output - EPA test wood 32,200 BTU/h
Maximum output - seasoned cord wood 75,000 BTU/h
Steel thickness (body) 3/16"
Weight 537 lb (244 kg)
Firebox volume (cu. ft.) 2.4 cubic feet
Glass Type Ceramic glass
Depth - Overall 25 5/8"
Height - Overall 36-7/8"
Width - Overall 27-1/8"
Center line of flue outlet to the back 6 3/8"
Centre line of flue outlet to the side 13-1/2"
Canadian Standard (emissions) CSA B415.1-10
USA standard (emissions) EPA Method 28 (40 CFR Part 60)
Canadian Standard (safety) ULC S627
USA standard (safety) UL 737, UL 1482
Type of Fuel Wood
Type of Chimney 2100 °F
Minimum chimney height 12'
Log Positioning Over width
Recommended Heating Area 750 - 2,100 sq ft
Steel thickness (top) 5/16"
Optimum efficiency 77.2%
Emissions 3.89 grams/hour
Baffle High heat-resistant C-cast
Recommended chimney diameter 6"
Warranty Limited Lifetime
Tested or/and listed as per applicable standards by Intertek
Minimum clearances to combustibles *
(Data expressed in inches. 1 inch = 25.4 mm)
USA / CANADA - Single Walled Pipe
Back 15"
Sides 16"
Corners 10"
Top** 84"
USA / CANADA - Double Walled Pipe
Back 6"
Sides 14"
Corners 6"
Top 84"

* The information given on the certification label affixed to the appliance always overrides the information published in any other media (owner's manual, catalogues, flyers, magazines and/or web sites).

** Measured from floor. Some appliances have been tested with a low ceiling. If necessary, consult the owner's manual for information on these clearances to combustible materials.

Matrix Wood Stove - OBO2020 Price
Stove with Original Finish Matrix Wood Stove $2,499
REQUIRED ACCESSORIES Price
BLACK Side Panel Kit Steel Side Panels $350
SOAP STONE Side Panel Kit Soapstone Side Panels $690
OPTIONS Price
Firescreen Firescreen $140
Flexible Insulated Fresh Air Intake Pipe (4' long/5 " diameter) $35

All Retail Prices Include: Residential, curbside delivery via freight truck with a lift gate is included for shipping in the Continental U.S.A. (some exceptions may apply). Please inquire with our sales staff if you have specific shipping needs such as international, freight terminal and/or business deliveries or if you need a smaller truck size. Click here to see Obadiah's Shipping Terms.

Obadiah's offer's a 20% discount and free shipping on most complete chimney systems. Email our chimney specialists for an exact quote.
