Napoleon LHD45 Linear Direct Vent Gas Fireplace

LHD45 Linear Napoleon Direct Vent Gas Fireplace

The Napoleon LHD 45 Vector Linear Gas Fireplace is perfect for new building and renovation projects. Be sure to check out all our installation videos for the LHD45, located under the "specifications" tab below.

  • UNIT INCLUDES: ELECTRONIC IGNITION WITH BATTERY BACK-UP, RIBBON BURNER, EXCLUSIVE "TOPAZ" CRYSTALINETM EMBER BED, STAINLESS STEEL FLEX CONNECTOR WITH SHUT OFF, DUAL RECEPTABLE JUNCTION BOX, PIVOTED HEAT RESISTANT GLASS DOOR, 20 FT. WIRE AND FIRESTOP. NON COMBUSTIBLE FACING MATERIAL INCLUDED. BATHROOM/BEDROOM/BEDSITTING ROOM/MOBILE HOME APPROVED. 24,000 BTU'S



  • Description
  • Specifications
  • Photos (6)
  • Pricing
  • Videos (1)
  • Add Review

This modern, LHD45 Linear gas fireplace is specifically designed to provide you with a sophisticated fire element that is perfect for both new building and renovation projects. The LHD45 Linear comes standard with Napoleon’s exclusive Topaz CRYSTALINE™ ember bed that sparkles with a luxurious glow. To create a dramatic mix, optional river rocks and coloured glass are available to replace or enhance the Topaz CRYSTALINE™ ember bed.

LDH45 Linear Direct Vent Gas Fireplace EXCLUSIVE FEATURES:

  • Clean, contemporary design with fuel saving electronic ignition and battery back-up
  • Exclusive Topaz CRYSTALINE™ ember bed
  • Pivoted glass door that radiates heat into the room
  • Up to 24,000 BTU’s
  • Stylo™ glass front is available to complement the contemporary design
  • Certified for bedrooms, bathrooms, bed sitting rooms and mobile homes
  • Backed by President’s Limited Lifetime Warranty
  • Ground level and above installations
  • Approved for installation in bathrooms, bedrooms and bed-sitting rooms
  • Suitable for mobile home installations

Check all Local and National Building Codes and Gas Regulations.

Options

  • Power vent option available
  • Basic four-sided contemporary surround complete with safety screen is available in Painted Flat Black finish
  • Deluxe four-sided contemporary surround complete with safety screen is available in Painted Gloss Black, Painted Satin Brown or Painted Gloss White finishes
  • Premium four-sided contemporary surround complete with safety screen is available in brushed stainless steel finish
  • Designer fire art available in a metal coil or a nickel stix design that adds a unique fireplace element
  • Alternate river rocks and coloured glass (Blue, Amber, Black, Red and Clear) media kits are available to replace the glass embers supplied with the unit
  • Media enhancement kits of river rocks, GEO shapes and coloured glass are designed for random placement within the firebox as an addition to either the CRYSTALINE™ ember bed or any of the other optional media
  • Optional MIRRO-FLAME™ Porcelain Reflective Radiant Panels echo flames throughout the firebox
  • Optional ACS (anti-condensation switch)
  • Optional convenient on/off or thermostatic remote controls





Specifications LHD45 Linear Gas Fireplace
Fuel Natural Gas
Flue (Top Vent) 4" x 7" Direct Vent
BTU Input 24,000
Maximum Heating Efficiency (Steady State) 72%
Glass Type Heat Resistant
Electronic Ignition Yes
Mobile Home Certified Yes
Tested and Approved CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS: ANSI Z21.50 CSA 2.22 FOR VENTED GAS FIREPLACES
Weight 175 lbs

Optional Blower Installation

Trim Installation

Basic Surround Installation

Premium Surround Installation

Porcelain Panel Installation

Burner Removal Tutorial

Glass Media Installation

Accessing Gas Valve

Log Kit Installation

Rock Media Installation

Battery Back-Up Installation

Natural Gas to Propane Fuel Conversion




LHD45 Linear Napoleon Direct Vent Gas Fireplace

LHD45 Linear Napoleon Direct Vent Gas Fireplace
Glass Styles
LHD45 Linear Napoleon Direct Vent Gas Fireplace
Remote Options
LHD45 Linear Napoleon Direct Vent Gas Fireplace

LHD45 Linear Napoleon Direct Vent Gas Fireplace
Paint options
LHD45 Linear Napoleon Direct Vent Gas Fireplace
Retail Price List Vector LHD45 Linear Gas Fireplace
LHD45NSB Linear Fireplace - Natural gas $2,849
Required Accessories MUST CHOOSE ONE SURROUND TO COMPLETE UNIT
Flat Black - Basic 4-sided surround w/safety barrier (covers opening 461/2 " W x 19 " H ) $361
Gloss Black - Deluxe 4-sided surround w/safety barrier (covers opening 461/2 " W x 19 " H ) $537
Gloss White - Deluxe 4-sided surround w/safety barrier (covers opening 461/2 " W x 19 " H ) $537
Brushed Stainless Steel - Premium 4-sided surround w/safety barrier (covers opening 461/2 " W x 19 " H ) $848
Linear Frame - Grey (With Safety Barrier) $775
Options
Blower kit with variable speed and thermostatic control - GZ550-1KT $278
Blower-economy, with variable speed and thermostatic control -B440-KT $185
Conversion kit - Natural gas to propane - W175-0326 $49
Black Porcelain Reflective Panels $227
Glass Media Kit - Color Choices: black, blue, red, amber, clear, topaz (5lbs) $99
River Rock - Grey or Multi Color $134
Driftwood Log Set $309
Hot Air Distribution Kit - GA-566 $392
Hot air exhaust kit (GA-566 also required) $113
Extension kit, 5 ft flex vent - GA-70 $51
Wall Thermostat - Digital $64
Napoleon on/off hand held battery operated remote w/digital screen $92
Napoleon thermostatic hand held battery operated remote w/digital screen $144
