DS Stoves 300-09 Kozy King Furnace

DS Stoves 300-09 Kozy King Furnace

The Kozy King DS300-09 coal furnace is Amish made and is built for maximum efficiency and less fuel consumption.  This coal furnace's efficiency is partly due to it being fully automatic with a secondary afterburn.  The Kozy King is manufactured in the USA and is UL listed.

  • Description
  • Specifications
  • Photos (18)
  • Pricing
  • Videos (1)
  • Add Review

The DS300-09 Kozy King coal burning furnace by D.S. Machine Stoves is Amish designed and hand crafted to be clean burning and amazingly efficient - the 300-09 furnace has 85.1% efficiency!  Hot water or hot air bimetal regulators are standard in all DS Machine Stoves and the DS300-09 also has the following features.

Features:

• Burns coal
• Cast iron shaker grates
• Cast Iron, airtight fire and ash door
• Large loading door



• Large ash pan
• 3-speed blower
• 3/16” plate steel
• Fully automatic
• Wall thermostat controlled
• Fan and limit safety controls
• Cast iron baffle
• Special tubes through fire box for maximum heat circulation


• Removable oxygen afterburner
• Forced draft
• Insulated cabinet
• 80/20 combustion bypass
• Filter box left or right intake (18” x 18”)





Resources:
Specifications DS Stoves Kozy King DS300-09 Furnace
Fire box size 16" X 22"
Fire Chamber Volume 6.2 cu. ft.
Weight 730 lbs
Width 28.5”
Height 53”
Depth 29”
Depth including filter box 47”
Flue size* 8”
Warranty firebox 5 years
Height to center of flue 47”
Ash door size 5.5” X 16.5”
Load door size 14” X 14.5”
Heating sq. ft. Up to 3,000 sq. ft.
BTU rating 140,000
Blower capacity, 3-speed 1650-1350, 1100 cfm
Blower Static Pressure Low -1.47 psig
Blower Static Pressure High -1.42 psig
Plenum outlet size 18” X 18”
Efficiency 85.1%
Clearance from combustibles
Side and rear 18”
Front 48”
Top of plenum to ceiling 2”
Flue to wall 18”

*All units require a class “A” all fuel chimney installation that must conform to local and state codes.
