Country Stoves Carrollton 230 Wood Insert

Country Stoves Carrollton 230 Wood Insert

Elegant design meets efficient performance in the Country Stoves Carrollton 230 Wood-Burning Insert. Featuring proven Thermal Fin Technology, the cast-iron heat exchanger delivers steady, comfortable heat. The expansive, durable ceramic glass offers a clear view of the flames while maximizing heat transfer. With a wide selection of high-quality, versatile styling options, Carrollton 230 inserts are crafted to complement any décor with ease.

  • Description
  • Specifications
  • Photos (2)
  • Pricing
  • Add Review

Features

  • The Country Stoves Carrollton 230 heats up to up to 2,000 square feet!
  • Spacious 2.3 cubic foot firebox interior accepts up to 18” logs
  • 76,000 BTU’s/hour and heats up to 1,200-2,200 square feet
  • Thermal Fin heat exchanger creates 32% more surface area than a standard insert design resulting in more heat entering the room
  • Air-boost timer automatically adjusts the air intake control making startup and reloading easier
  • Tall opening provides and expansive view of the burning fire
  • Ceramic glass for extra strength and optimum heat transfer
  • Unique, integral air wash system keeps the glass clean and clear for a wide-open view of the fire
  • Precision-cut, heavy-gauge steel provides dependable, long-lasting operation
  • High-density firebrick retains heat longer, resulting in increased efficiency
  • One-touch control ensures easy operation and comfort
  • Standard 150 CFM variable speed blower quickly moves heat from the insert into your room
  • Choose from several sizes of surround panel kits to match your opening size (1-required)
  • Choose between a steel or cast-iron warming top (1-required)
  • Optional decorative door trim in Brushed Nickel or Nickel allow customization to your style
  • EPA-certified for clean and efficient operation
  • Limited Lifetime Warranty



Doors

Standard Black Brushed Nickel Trim Nickel Trim




Miscellaneous

Cast Iron Warming Surface Steel Warming Surface

Resources:
Specifications Carrollton 230
Dimensions (Front) 21-3/4"H x 36-5/8"W
Dimensions (Rear) 21-1/4"H x 24-1/2"W (Tapers to 22-1/2"W)
Depth into Fireplace 15-1/2"
Depth into Hearth 8-1/8"
Firebox Volume 2.3 cu. ft.
Firebox Viewing Size 11-5/16"H x 16-1/2"W
Flue Size 6"
Minimum Chimney Height 12 ft.
Fuel Wood
Heat Output 76,000 BTU/h
Max Log Length 18"
Efficiency 63%
Emissions 1.7 g/hr
Max Burn Time 8 hr
Heating Capacity 1,200-2,200 sq. ft.
