Obadiah’s 1600 Non-Catalytic Stove

Obadiah’s 1600 Non-Catalytic Stove

Obadiah’s 1600 Non-Catalytic Freestanding Woodstove by High Valley is highly efficient and durable.  It exceeds emission standards set by the EPA and even Washington State! Producing 60,000 BTU’s and designed with a stainless steel re-burn system to maximize performance, this rustic wood stove can heat spaces up to 2,700 square feet and burn steady for up to 15 hours. Whether you are high in the mountains or low in the valleys, this wood-burning stove can be the focal point of your home with the optional Traditional Style trim kit and rivet accents.



  • Description
  • Specifications
  • Photos (16)
  • Pricing
  • Videos (4)
  • Add Review

Obadiah’s has partnered with High Valley Stoves to bring you durable and efficient woodstoves.  After spending over a decade interacting with countless manufacturers and customers on how to get the most out of home heating, Obadiah’s is able to bring a seasoned quality to their stoves, that you simply won’t find anywhere else. As always, Obadiah’s puts the customer’s trust first because without our customers, there is no Obadiah’s.



Features

  • Single air control that regulates the fire
  • Air wash system cleans the ceramic glass viewing window
  • Double wall construction gives you convection heat with radiant heat from the front
  • Optional Variable speed 75 CFM blower with rheostat and bracket
  • Step-top cooking surface
  • Washington State Approved!
  • EPA approved
  • Mobile home approved (with the outside air kit)
  • Cast Iron Door
  • Non-Catalytic Combustion
  • Stainless Reburn Combustion Tubes
  • Firebrick Lined Firebox
  • Overnight Burntime
  • Flat Black Finish

Options

  • Plated Door Door Colors: Copper, Pewter, Dark Pewter, and Gold
  • Hand-Rubbed Color Finishes Available in Bronze, and Copper





Specifications Obadiahs 1600 Non-Catalytic Woodstove
Height 30"
Width 27"
Depth 30.5"
Weight 581 lbs
Firebox 2.7 cu ft
Max Long Length 21"
Flue 6" Top or Rear Vent
Rear Flue Height 28.75" to Flue Top
Emissions 2.7 gr/hr
Efficiency 79.7%
Burn Time Up to 15 hr
Output 60,000 BTU/hr
Heat Capacity Up to 2,700 sq ft
Blower 75 CFM
Tested UL 1492
Floor Protector UL 1618 Type 1 Ember Protection
Minimum Size US = 43"W x 49"D

Clearances to Combustibles

Wiring Diagram

Obadiah's 1600 Shown in Black, Pedestal, and Copper Door
Obadiah’s 1600 Non-Catalytic Stove
Obadiah's 1600 Shown in Standard Style Black, Cast Iron Legs, and Dark Pewter Door
Obadiah’s 1600 Non-Catalytic Stove
Obadiah's 1600 Wood Stove Traditional Style Hand-Rubbed Bronze, Steel Legs, and Trivet package
Obadiah’s 1600 Non-Catalytic Stove
Obadiah's 1600 Shown in Standard Style Black, Cast Iron Legs, and Dark Pewter Door Side View
Obadiah’s 1600 Non-Catalytic Stove
Obadiah's 1600 Shown in Hand-Rubbed Copper, Steel Legs, and Copper Door - Front View
Obadiah’s 1600 Non-Catalytic Stove
Obadiah's 1600 Hand Rubbed Bronze Top View
Obadiah’s 1600 Non-Catalytic Stove
Obadiah's 1600 Shown in Hand-Rubbed Copper, Steel Legs, and Copper Door
Obadiah’s 1600 Non-Catalytic Stove
Obadiah's 1600 Shown in Hand-Rubbed Bronze Trivet Package, and Steel Legs - Top Side View
Obadiah’s 1600 Non-Catalytic Stove
Obadiah's 1600 Shown in Hand-Rubbed Bronze 6" Flue Collar Top View
Obadiah’s 1600 Non-Catalytic Stove
Obadiah's 1600 Shown in Hand-Rubbed Bronze, and Cast Iron Legs - Rear View
Obadiah’s 1600 Non-Catalytic Stove
Obadiah's 1600 Shown in Hand-Rubbed Bronze 3/8" Top Thickness
Obadiah’s 1600 Non-Catalytic Stove
Obadiah's 1600 Firebrick Lined Firebox
Obadiah’s 1600 Non-Catalytic Stove
Obadiah's 1600 Firebox Stainless Re-Burn Tubes
Obadiah’s 1600 Non-Catalytic Stove
Obadiah's 1600 Shown in Hand-Rubbed Bronze 6" Flue Collar
Obadiah’s 1600 Non-Catalytic Stove
Obadiah's 1600 Shown in Black Production Line
Obadiah’s 1600 Non-Catalytic Stove
Obadiah's 1600 Shown in Black Production Line - Side View
Obadiah’s 1600 Non-Catalytic Stove
Product Price
Obadiah's 1600 Non-Catalytic Stove, Pedestal (Top or Rear Vent) $2,011.00
Obadiah's 1600 Non-Catalytic Stove, Cast-Iron Leg (Top or Rear Vent) $1,988.00
Obadiah's 1600 Non-Catalytic Stove, Steel Leg (Top or Rear Vent) $1,949.00
Door Options
Plated Antique Copper, Dark Pewter or Antique Brass Doors $455.00
Finishes
Burnished Copper or Burnished Bronze Stove & Door Finish $190.00
Options
Old World Style Package (Includes Old World Trim, Rivet Door and Legs or Pedestal) $689.00
75 CFM Blower with Rheostat and Bracket $230.00
Decorative Rivets (Painted door only) $190.00
Outside Air Kit (only available with Pedestal) $69.00

Residential, curbside delivery via freight truck with a lift gate is $100 charge for shipping in the Continental U.S.A. (some exceptions may apply). Please inquire with our sales staff if you have specific shipping needs such as international, freight terminal and/or business deliveries or if you need a smaller truck size. Click here to see Obadiah's Shipping Terms.

  • Obadiah's offer's a 15% discount and free shipping on most complete chimney systems. Contact our chimney specialists for an exact quote.
